V-MAC Co-Pilot Operator's Manual 123 CO-PILOT® OPERATIONS This chapter is intended as a general overview to operations.
Using the Co-Pilot® Note: Turn the ignition key to the ON position before operating the Co-Pilot®. When the ignition key is turned to the ON position, the Co-Pilot® automatically turns on. The MACK LOGO INTRO screen (refer to Figure 40) appears for several seconds and is usually followed by the last Anytime screen that was active prior to power-down. If vehicle management and control (V-MAC) IV is programmed to “get driver” at key-on or for theft deterrence (refer to Figure 41), then the CHANGE DRIVER screen (refer to Figure 52) will appear. Messages on the screen will prompt ↵ ) button to accept the driver ID or use the Co-Pilot® the driver to press the Enter (↵ stalk switch to enter a password. ↵ ) button before beginning a trip to make the Remember to press and hold the Enter (↵ stationary MAIN MENU screen appear. ↵ ) button on the stalk switch to turn it on. Note: If the screen is black, press the Enter (↵ Note: It is also possible to retrieve engine hours and odometer readings with the ↵ ) button on the stalk switch. ignition OFF; simply press and hold the Enter (↵
