V-MAC Co-Pilot Operator's Manual 109 DEL Messages The DEL MESSAGES submenu screen is accessed from the stationary MAIN MENU 2 screen (see). The DEL MESSAGES submenu contains a list of driver event logging messages. A driver may choose to log a driver event logging message depending on the driver's activity. For example, if the driver is going to leave a terminal, the driver would select the LEAVE TERMINAL message. To view the list of driver event logging messages in the DEL MESSAGES submenu, highlight “Messages” with the stalk switch Up & Down button and then press the ↵ ) button to select the message to log. Enter (↵ Note: The DEL MESSAGES submenu is optional and will only appear if enabled in VCADS software or MACKtraq. The DEL MESSAGES submenu contains the following driver event logging messages:
• Leave Terminal • Arrive Terminal • Load Pick Up • Load Delivery • Leave Job Site • Arrive Job Site
C0035404
Figure 57 — DEL Messages Screens
