V-MAC Co-Pilot Operator's Manual
Diagnostics The Diagnostics submenu screen is accessed from the stationary MAIN MENU 2 (see). To view the screens of the DIAGNOSTICS submenu, highlight “Diagnostics” ↵ ) button to with the stalk switch Up & Down button and then press the Enter (↵ select the screen. The DIAGNOSTICS submenu screen contains the following main screens:
• Cluster Diagnostics — Allows the user to test bulbs, pointers on gauges, graphics and alarms associated with the cluster.
• Hardware/Software Part Numbers — Allows the user to view the hardware and software part numbers of the engine control module (ECM), anti-lock braking system (ABS) electronic control unit (ECU), instrument cluster and vehicle ECU.
W3075371
Figure 51 — Diagnostics Submenu Screens
