V-MAC Co-Pilot Operator's Manual 95 CO-PILOT® MENU SCREENS Main Menu — Stationary Vehicle The MAIN MENU screen consists of two screens for a stationary vehicle: stationary MAIN MENU 1 screen and stationary MAIN MENU 2 screen. To cause the stationary MAIN MENU 1 screen to appear, press and hold the stalk ↵ ) button when in the CURRENT CONDITIONS screen (see). To switch Enter (↵ cause the stationary MAIN MENU 2 screen to appear, scroll down on the stalk switch Up & Down button.
W3036587
Figure 42 — Stationary Main Menu Screens From these two menus, the driver can access the following information supplied in a submenu structure:
• Fuel Economy (Anytime and Stationary Screens) • Trip Information (Anytime and Stationary Screens) • Gauges (Anytime and Stationary Screens) • Fleet Management (Stationary Screens) • Diagnostics (Stationary Screens) • Maintenance (Stationary Screens) • Integrated Temp-A-Start (if available; for future support) • Driver Event Messages (Stationary Screens) • Settings (Stationary Screens) Note: To view any of the above submenus from the stationary Main Menu screens, use the stalk switch Up & Down button to highlight an item and then press the stalk ↵ ) button to make your selection. switch Enter (↵ Also included in the stationary MAIN MENU 1 is the selection of a black-out panel. Detailed information on these submenus and their screens is available in and .
