LUBRICATION
HYDRAULIC SYSTEM Check the hydraulic reservoir fluid level...................... Every 10 hours or each day Check the lines................................................................................ Every 50 hours Replace the hydraulic breaker return circuit filter .......................... Every 100 hours Draining water and sediment from the hydraulic reservoir ...................................................... Every 250 hours Check the condition of the hydraulic fluid.................................... Every 1000 hours Replace the pilot filter.................................................................. Every 1000 hours (after the first 50 hours during the run-in period) Replace the reservoir breather element...................................... Every 1000 hours Clean the suction filter................................................................. Every 2000 hours Replace the return filter............................................................... Every 2000 hours (after the first 50 hours during the run-in period) Replace the Nephron filter .......................................................... Every 2000 hours Replace the suction filter ............................................................. Every 5000 hours Change the hydraulic fluid........................................................ Every 10 000 hours Reservoir capacity 130 LX and 160 LX .........................................73 litres (19 gal.) Total system capacity 130 LX.......................................................123 litres (32 gal) Total system capacity 160 LX.......................................................148 litres (39 gal) Type of oil............................................................................................... ISO VG 46 Note: If the machine is new or if a major part has been overhauled or replaced in the hydraulic system, replace the pilot filter and return filter after 50 hours of operation. After that, replace these filters at the stipulated interval. IMPORTANT: Every 1000 operating hours, it is necessary to have the hydraulic fluid analysed. See your authorized LBX Link-Belt distributor. IMPORTANT: After replacing the hydraulic fluid, it is necessary to bleed all air from the hydraulic components. See “Bleeding air from the hydraulic components”. IMPORTANT: If metal filings are discovered in the replaced filters, see your authorized LBX Link-Belt distributor.
149
TRIM THIS EDGE RIGHT PAGE Bur 6-25600
TRIM THIS EDGE
Service specifications
