LUBRICATION
FUEL SYSTEM Service specifications Draining water and sediment from the fuel tank.............................. Every 50 hours Draining water from the water separator ......................................... Every 50 hours Fuel filter replacement................................................................... Every 500 hours Fuel tank capacity 130 LX and 160 LX ........................................250 litres(66 gal.) Type of fuel.................................................................................................... Diesel
Draining water and sediment from the fuel tank
Draining water from the water separator A
1
CD00E107
CD00E174
Remove upper undercover. Have a container ready to collect the drained contaminants. Open the drain valve located at the bottom of the tank and drain the accumulated sediment and water into a suitable container. After draining, close the drain valve.
When the float reaches the level line (A) Loosen the drain plug (1) and drain the water and sediment into a suitable container. When the float (2) settles on the bottom, tighten the drain plug (1). Verify that there are no fuel leaks.
Replace upper undercover.
!
Warning: Completely wipe off any spilt fuel. It may cause a fire.
145
