OPERATING INSTRUCTIONS
FILLING THE BUCKET Fill the bucket by maneuvering the arm. Keep the bottom of the bucket parallel to the cut. The bucket teeth and blade must cut the ground like the blade of a knife. The depth of dig varies depending on the type of material.
Excavating method
PDH0494M
CORRECT
WRONG
WRONG
The bucket will dig in and cause a stall.
The bucket is pushed upwards. This will also increase the cycle time.
