Fuses and relays
4.3.2
F19 F19-2
100 A 100 A
Circuit breaker on terminal Kl30 Heater flange I Circuit breaker on terminal Kl30 Heater flange II
F20 F31
80 A 7,5 A
Circuit breaker on terminal Kl30 Main circuit Fuse on Kl15 / heater and air conditioning unit, refueling pump
F37
20 A
Fuse on Kl30 / heater and air conditioning unit
F50
15 A
Fuse on Kl30 / Heating resistor in fuel prefilter
F109
50 A
Circuit breaker on terminal Kl30 / special equipments and floodlights
F110
50 A
F115
7,5 A
Circuit breaker on Kl30 / power terminal of Electronic Diesel Control system Fuse on Kl15 / Control circuit for heating resistor in fuel prefilter
F116
7,5 A
Fuse on Kl30 / controller on Electronic Diesel Control system
F117 F122
7,5 A 7,5 A
Fuse on Kl15 / Electronic Diesel Control system Fuse on Kl30 / Preglow signal to Electronic Diesel Control
F123
7,5 A
Fuse on Kl30 / Preglow signal to Electronic Diesel Control
F130
15 A
Fuse on Kl30 / Floodlights on attachment
F131 F132
15 A 15 A
Fuse on Kl30 / Horn Fuse on Kl30 / Reserve
F150
15 A
Fuse on Kl15 / Servo control system and servo control plates
F151 F152
15 A 15 A
Fuse on Kl30 / Servo control plate U48-1 Fuse on Kl30 / Servo control plate U48-2
F153 K56
15 A
Fuse on Kl30 / Servo control plate U46 Relay / Heating resistor in fuel prefilter
K127 K128
Relay / engine RPM adjustment in safety mode Relay / engine start in safety mode
K222
Relay / Servo control system on
K288 K302
Main relay / Terminal 15 Relay / Heater flange on intake air manifold I
K302-2
Relay / Heater flange on intake air manifold II
Control plate A1010 with fuses The remaining fuses and circuit breakers are mounted to the printplate A1010, located in the electrical box of the left control console. Danger Incorrect or bypassed fuses do not offer the operator or the electrical system of the machine the required degree of protection.. Only use original fuses. Never repair or bypass electrical fuses. If required, order replacement fuses from LIEBHERR.
