Control and operation
Operating manual
Working with the machine
3.4 Working with the machine 3.4.1
The travel movements Straight travel
Fig. 3-63 1 2
Straight travel
Idler wheel Sprocket wheel
5 Left travel pedal 6 Right travel pedal
Caution! When travelling the machine, the upper carriage must be rotated to the undercarriage in such a way that ,during forwards travel, the idler wheel 1 is in front and the sprocket wheel 2 is at the rear. Travelling forwards: Push the both travel pedals forwards (5a + 6a). Travelling backwards: Push the both travel pedals down (5b + 6b). Caution! Before you travel in reverse, make sure the area behind the machine is free of any obstacle and nobody is in your way.
copyright by
3 - 80
MJFCIFSS
R 974 C / 10069856
