Control and operation
Operating manual
Operating and control elements
Joysticks in standard execution
Fig. 3-3
Arrangement of push buttons and switches in the joysticks in standard execution
Left joystick
Right joystick
Push button S5L: Rotating device left See in this chapter "Turning, rotating, bolting and unbolting the add-on unit" and "Control of the swivel rotator (option)".
Push button S6L: Lifting magnet See in this chapter "Lifting magnet control system (optional equipment)".
Push button S5M: Horn
Push button S6M: For optional equipment See in this chapter "Float position of the boom with shovel attachment" in the part "Working attachment control"
Push button S5R: Rotating device right See in this chapter " Turning, rotating, bolting and unbolting the add-on unit" and "Control of the swivel rotator (option)".
Push button S6R: For optional equipment See in this chapter "Drive warning device (optional extra)" and "Control of the swivel rotator (option)".
Push switch S55: For optional equipment See in this chapter "Cut off by end switches of attachment movements (option)".
Rocker switch S57: Reserve
Tab. 3-1
Functions of push buttons and switches in standard execution
copyright by
3-4
MJFCIFSS
R 906 Classic / 10359873
