Troubleshooting
Operating manual
Fuses and relays
Fig. 4-3
Fuses and relays, A1010 plate
F1
Fuses on terminal 15 (Kl15) 15 A Lubrication swing uppercarriage, central lubrication system
F2
15 A Reserve
F3
15 A Reserve - windshield wiper and washer on cab roof
F4
15 A Windshield washer, control circuit of windshield wiper, preheating system control circuit, 24 Volt stabilized for transmitters and switches, Qmin commutation, pressureless lowering, beacon*, rotating grab*
F5 F6
15 A Windshield wiper motor (power circuit) 7,5 A for safety mode
F7
7,5 A Control unit and display
F8
15 A Safety lever, solenoid valve for servo control, swing brake, travel speed increase, pressure increase 15 A power supply for BST regulator
F9
Fuses on terminal 30 (Kl30) F10 25 A Headlights on working attachment and uppercarriage front F11 15 A Reserve
copyright by
4 - 18
MJFCIFSS
R 906 Classic / 10359873
