Control and operation
Operating manual
Installation and removal of attachment parts
Connect or separate the hydraulic coupling slowly as with any change of work tool. When attaching the quick-change adapter, tilt until the coupling disks are connected as a result of the self weight of the work tool. Remove the locking pins. If the disks do not connect as a result of self weight, foreign matter (such as stones) may be the cause. In this case, clean all coupling parts to prevent damage occurring when connecting. Oil quantity and pressure must be adapted to suit the work device concerned. When the work is completed, and particularly before transportation, put the protective coverings 1 and 2 back on.
Attaching LIKUFIX work tools to a quick-change adapter without LIKUFIX It is possible to attach a work tool with a LIKUFIX hydraulic coupling to a machine with a quick-change adapter (mechanical or hydraulic) at any time.
Fig. 3-116 LIKUFIX work tool on quick-change adapter without LIKUFIX Caution! The LIKUFIX hydraulic coupling could be damaged. Do not use a quick-change adapter with a reinforcement kit since the reinforced steel part 6 could damage the LIKUFIX hydraulic coupling on the work tool. In this case, ensure that you have the quick-change adapter reworked at the LIEBHERR customer service centre. For attachment without LIKUFIX hydraulic coupling, LIEBHERR work tools usually have an alternative connection option. Example: On the ditcher bucket, hydraulic lines are either connected using LIKUFIX 4 or using an auxiliary hydraulic connection 5.
