Control and operation
Operating manual
Installation and removal of attachment parts
Turn off the engine and, with the ignition key in the contact position, push the right joystick briefly to the left and then to the right in order to remove the pressure in the hydraulic circuits.
Turn the lever of each valve block 15 in position A (Position A, bucket operation) and push the right joystick briefly to the left and then to the right in order to remove the pressure in the hydraulic circuits. Push the safety lever up. Separate hydraulic hose 11, hydraulic hose 12 and, if present, hydraulic hoses 13 and 14 from the pipes on the stick. Close open lines immediately to prevent any dirt entering. Support the grab so that it is stable. Remove the plate 6. Drive out the pin 4 and remove the pin bearing sealings 25. If necessary, start the engine and lift the attachment slightly to remove the pin 4.
copyright by
3 - 122
MJFCIFSS
R 906 Classic / 10359873
