Control and operation
Operating manual
Working with the machine
The load capacity values achieve a maximum of 75% of the tip load or 87% of the hydraulic lifting power according to ISO 10567. The permissible load capacity is related to the factors that follow:
The overload warning device does not release the machine operator from the responsibility of only lifting loads that are known and within the safe working load of the machine in accordance with the load lift chart. With the specified load, the machine can be rotated from 360° on even and horizontal ground.
Check of the overload warning system The overload warning system must be checked for correct function every time the machine is started and before load lifting work. Slowly extend the hoist cylinder to the stop. Operate the hoist cylinder to the stop. The overload warning status symbol appears on the display. An audio warning sounds in the operator cab. If a malfunction occurs: Do not lift loads. Have the overload warning system repaired.
Operation of the overload warning system DANGER! Tipping over of the machine! The overload warning system does not shut down the machine if the permissible load torque is exceeded. The operator of the machine is only informed of the situation. Death. Follow the safety instructions related to load lifting. Follow the instructions if the overload warning system is triggered. Push the key S18. The overload warning system is activated. The LED of the key comes on. If the overload warning system is triggered: overload warning status symbol is shown on the display.
Reduce the reach. or Lower the load to the ground without increasing the reach.
