Control and operation
Operating manual
Working with the machine
Standard control
Fig. 3-81
Commutation of standard control for an additional attachment
The additional attachment can be operated alternatively with the left double pedal or with the right joystick. The commutation of control can be activated with the key switch S114 on the rear right control desk. Turn the key switch S114 to select the joystick position. The additional attachment is now operated with the right joystick (movements to e and f). The bucket tilt function is now operated with the left double pedal (m-k). The key is locked in the switch S114. Turn the key switch S114 to select the foot pedal position. The additional attachment is now operated with the left double pedal again. The key can be removed from the switch S114.
Proportional control Mini joystick / Joystick
Fig. 3-82
Commutation of proportional control for an additional attachment
copyright by
3 - 100
MJFCIFSS
R 906 Classic / 10359873
