Control and operation
Operating manual
Working with the machine
Press again the push button S21. the LED 1 in the push button goes out. the automatic commutation between normal travel speed and increased travel speed is deactivated and the travel motors remain continually in position 1.
The travel brakes Hydraulic braking The hydrostatic travel drive of the machine also functions as a service brake. When the travel pedals are released, the pedals will return automatically to the neutral position. a maximum hydraulic braking of the machine is achieved. the travel movement is stopped. When the machine is travelling down a slope , automatically acting hydraulic braking valves prevent the machine from running away and the maximum travel speed cannot be exceeded.
Mechanical braking A negatively acting, hydraulic multi disc brake is integrated in each travel gear. These brakes serve as parking brake. As soon as a travel pedal is actuated, the brake at the corresponding travel gear is released. As soon as a travel pedal is returned to neutral position, the mechanical brake at the corresponding travel gear is applied. Caution! Disengaging the pedals quickly causes the machine to halt abruptly. Before starting the machine, always fasten the safety belt.
Limit of gradeability Danger! Risk of tipping over! The machine has a maximum gradeability of 35°. This limit is valid for a machine travelling straight up or down the slope, with the uppercarriage aligned with the undercarriage and under appropriate adherence and stability conditions. This limit is only valid for translation and not working on a slope. This limit is only valid for a standard machine with standard attachment and takes into account the hydraulic and mechanical power losses.
Note! To know the maximal slope the machine can work in, contact the customer service because this value depends on the configuration of the machine. The stability values given in the technical datas of the machine (chapter 1.2 of this manual) are valuable only for an horizontal and firm level ground.
copyright by
3 - 84
MJFCIFSS
R 906 Classic / 10359873
