Page 168

Control and operation

Operating manual

Working with the machine

Travel forwards: Push both pedals forward at the same time (5a and 6a). Travel backwards: Caution! Before travelling in reverse, ensure that the area behind you is clear and nobody is in your way. Push both pedals down at the same time (5b and 6b).

Counter rotation with both tracks

Fig. 3-61

Counter rotation with both tracks

Counter rotating left (A): Push the left pedal down (5b). Push the right pedal forwards at the same time (6a). Counter rotating right (B): Push the right pedal down (6b). Push the left pedal forwards at the same time (5a).

Turning over one track

Fig. 3-62

Turning with a crawler

Turning ahead to the left (A): Push the right pedal forwards (6a). Turning ahead to the right (B): Push the left pedal forwards (5a).

copyright by

3 - 82

MJFCIFSS

R 906 Classic / 10359873
