Control and operation
Operating manual
Access and equipment of the cab
Fig. 3-34
Operator seat
1 3
Operator seat heating Backrest adjustment
2 4
Mechanical / pneumatic lumbar support* Armrest height adjustment
5
Armrest adjusting wheel
6
Horizontal suspension*
7
Horizontal adjustment with 8 Display for weight settings* control consoles Manual/automatic adjustment 10 Shock absorber* for body weight and seat height*
9
11 Horizontal adjustment 13 Seat inclination
12 Seat depth 14 Safety belt
15 Armrests
16 Headrest
* Model variant
Adjusting seat to body weight/seat height (in models with manual adjusting mechanism): Sit down on the seat. Adjust the seat height/body weight by pulling or pushing the lever 9 to the stop. Check the display 8.
If necessary: Adjust the settings by pulling or pushing the lever 9 to the stop. Adjusting seat to body weight (in models with automatic adjusting mechanism)*: Before adjusting the body weight settings, set the shock absorber* to "soft".
