Control and operation
Operating manual
Access and equipment of the cab
Getting out Caution! Entering or leaving the cab incorrectly could lead to injury. Proceed with the same attention on exit or entry of the cab, as while climbing the machine. Ensure that the safety lever is always in its highest position when entering or leaving the cab. Always use the handholds provided for the purpose when entering or leaving the machine. Face the machine when getting in or out and always use three-point support, i.e. two hands and one foot or two feet and one hand must always be in contact with the access system at the same time. Do not hold onto the controls to steady yourself. Never jump from the machine.
Fig. 3-32 3
Door - interior
Door handle on door lock
4
Lever for the latch
Switch off the machine and push the safety lever up. Push the door handle 3 on the lock down. Open the door fully and secure it in the latch 2. Climb out with your face towards the machine. To release the door latch: The door is secured in latch 2. Move the lever 4 next to the cab frame outwards. The door is now unlocked. Close the door.
copyright by
3 - 44
MJFCIFSS
R 906 Classic / 10359873
