Control and operation
Operating manual
Operating and control elements
n when operating a super long working attachment When using a long reach attachment (super long working attachment with a smaller digging tool), this device allows to limit the working pumps oil flows to a value admissible for all the hydraulic cylinders of the working attachment. Turn the key switch S168 to the right, in po movements of the working attachment.
See the section "Height and inclination adjustable cab (optional equipment)" in this chapter.
When the ignition is switched on, pressing this switch activates the cab roof window wiper. Press this switch wich is on the right control panel.
This unit controls an eventually installed standstill heater for the cab or for other circuits on the uppercarriage. Refer to the special issued operation and maintenance manual of the maker of the additional heater.
By pressing on this touch the indicator integrated in the touch lights up and the second characteristic curve for the proportional function of the left joystick is selected. function By pressing on this touch the indicator integrated in the touch lights up and the second characteristic curve for the proportional function of the right joystick is selected.
This touch switch on and off the additional floodlight.
This touch switch on and off the additional floodlight.
The button turns on the electric cab roof window washer system. Washer fluid will be sprayed to the window and the cab roof window wiper will be actuated as long as the push button S362 is depressed. S422 - Radio muting
copyright by
3 - 40
MJFCIFSS
R 906 Classic / 10359873
