BRAKES
L2501, WSM
4. CHECKING AND ADJUSTING Brake Pedal Free Travel WARNING To avoid personal injury or death: • Stop the engine and remove the key, then chock the wheel before checking brake pedals. 1. Release the parking brake. 2. Slightly depress the brake pedals and measure free travel "A" at top of pedal stroke. 3. If the measurement is not within the factory specifications, loosen the lock nuts (1) and turn the brake rods (2) to adjust them within the factory specifications. Brake pedal free travel A
Factory specification
15 to 20 mm 0.6 to 0.8 in.
IMPORTANT • Keep the free travel in the right and left brake pedals equal. NOTE • The difference between the right and left pedal free travels must be less than 5 mm (0.2 in.). • After checking brake pedal free travel, be sure to engage the parking brake lock fully and check to see that the brake pedals are securely locked. (1) Lock Nut (2) Brake Rod
A:
Free Travel 9Y1211121BRS0003US0
5-S4
KiSC issued 09, 2014 A
