BRAKES
L2501, WSM
1. FEATURES (1) (2) (3) (4) (5) (6)
Brake Case Cam Plate Brake Cam Brake Cam Lever Brake Rod Brake Pedal
Independent mechanical wet disc brakes are used for the right and left traveling brakes. They are operated by the brake pedals through the mechanical linkages. The parking brake is a mechanical type which is designed to actuate the traveling brakes through the linkage. Pushing the parking brake lever results in the same state as that obtained when the brake pedals are pressed. 9Y1211121BRM0001US0
5-M1
KiSC issued 09, 2014 A
