Assembly process No.
A-26
Installation of fuel quick charge piping (if equipped) (1/2)
(1) Remove the blind plug from the left top of the fuel tank and connect the hose. (Fig. 1) (2) Remove the left ripper pin lock plate and install the brackets and tubes. (Fig. 1) (3) Connect the hoses to the tubes. (Fig. 1) (4) Fix the hoses to the fuel tank with the clamps. (Fig. 1) (5) Tighten the U-bolts permanently so that the tubes will be set in the specified directions. (Fig. 2)
A (8), (9) is assembled already.
150
