Assembly process No.
A-21
Installation of platform (if equipped) (1/4)
1. Replacement of rear support upper bracket (1) Remove rear covers (1), (2), (3), and (4). (2) Remove brackets (5) and (6) and install brackets (7) and (8). (3) Install rear covers (1), (2), (3), and (4).
2. Installation of platform (4) Install brackets (11), (12), and (13) by using bolts (14) and (15). When installing brackets (12) and (13), tighten the bolts so that no clearance is made between the brackets and fender mounting seats.
For details of each part, see (4/4).
138
