SERVICE MANUAL FOR TC213F Standard value Usable limit +0.05
Front bush bore
Ø35 +0.034 mm
0.2 mm
Rear bush bore
Ø62 +0.116 mm
+0.186
0.2 mm
* Bush bore should be measured when the bushes are installed.
IV. PRECAUTIONS FOR RE-ASSEMBLY (1) When replacing the shaft seals of the rotation parts of the final case and wheel shaft, never hit the surface of the flange of the sleeve. Damaged flange surfaces will cause oil leaks. Jig Sleeve
Improper
Proper
Fig. 6-4
(2) When sub-assembling the differential, insert the spring pin so as for the seal to turn in the direction of external force applied. After inserting the spring pin, retain it with wire. Seam of roll pin should face in direction in which load is applied.
Fig. 6-5
52
