SCMA54,SCMB60,SSM54
CHAPTER 2. ATTACHING AND DETACHING MOWER DECK WARNING: When attaching or detaching the mower deck to the front mower: ・Place the front mower on level, hard ground. ・Apply the parking brake securely. ・D o n o t s t a r t t h e e n g i n e e x c e p t f o r operating the mower lift lever. 1.
ATTACHING THE MOWER DECK
Attach the mower deck first to the front mower and then connect the drive shaft. ■ INSTALLATION OF MOWER DECK a.
Start the engine and shift the mower lift lever to “UP” position to lift up the lift arm, then stop the engine. Insert the chuter hose into the blower hall, hook the chuter on lower frame.
b.
Put the mower deck in front of the front mower, shift the mower lift lever to “DOWN” position, then lift down the lift arm.
c.
Assemble the right-hand and left-hand lift arms to the mower deck, with pin.
IMPORTANT:
When it is difficult to align the hole in the lift bracket and the hole in the link ball, never attempt to insert the pin forcibly. But sway the mower deck right and left and the pin can be inserted easily.
d.
Attach the chuter on mower deck, fix it by lock pin.
e.
Start the engine and lift up the mower deck. Stop the engine and fix the fulcrum plate in the back of the mower deck to the folk under the lift rod by inserting pin and hair pin. Lower the mower deck onto the ground.
86
