SF224,235 17.
ENGINE OIL FILTER
IMPORTANT: ・The engine oil filter should be replaced after the initial 50 hours of operation and then after every 400 hours of operation. ・It is recommended to ask your dealer to replace the engine oil filter, because this operation requires a special tool. But when there is no alternative but to replace the filter by yourself, observe the following instructions. The engine oil filter,1, is located on the left-hand wall of the cylinder block. a.
Drain engine oil completely following the instructions of "16. ENGINE OIL REPLACEMENT."
b.
Place a tray or like under the engine oil filter to receive dripping oil when the filter is replaced.
c.
Loosen the filter using a filter wrench and remove it.
d.
Install a new filter with the O-ring lubricated with new engine oil. Screw in the filter until its packing comes into contact with the sealing surface of the engine and then tighten it by a 2/3 turn with the filter wrench.
e.
Pour oil in referring to "16. ENGINE OIL REPLACEMENT."
18.
FIG. 78 (1)
TRANSMISSION OIL REPLACEMENT
IMPORTANT: ・The transmission oil should be replaced after the initial 50 hours of operation and then after every 300 hours of operation. ・It is recommended to ask your dealer to replace the transmission oil, because this operation also requires washing or replacement of the suction filter. But when there is no alternative but to replace the filter by yourself, observe the following instructions.
64
Engine oil filter
