SF224,235 10.
BRAKE PEDAL PLAY
Depress the brake pedal,1, and apply the parking brake, 2. Adjust the length of brake rod, 3. Release the parking brake lever and make sure that there is play on the brake arm. DANGER: ・As the front mower is used, the brake pedal play becomes larger. Excessive play will affect the proper brake performance, which is very dangerous. ・Before operation, be sure to check the brake pedal play. (1) Brake pedal
(2)
(see from top)
FIG. 69 (see from right side)
(1) (4)
Brake pedal Lock nuts
(2) Brake rod (M08x120) (5) Brake arm
FIG. 70 (3) Brake rod (M08x72) (6) Parking brake lever
58
FIG. 68 Parking brake
