CHAPTER 1. NAMES OF MAJOR COMPONENTS
CHAPTER 1. NAMES OF MAJOR COMPONENTS 1.
SBC950F-HE4
12
7
13 16
8
9 15 (1) (2) (3) (4) (5) (6)
Container Lift link Dump link Lift cylinder Dump cylinder Rear door
(7) (8) (9) (10) (11) (12)
Container limit sensor Door hook Blower chuter Collector main frame Cleaning stick Swing cover
113
(13) (14) (15) (16)
Swing motor Container base Container sensor Door lock release bolt
