TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES 1.
The 10 m (33 ft) or 17 m (56 ft) boom extension shall be erected at minimum offset. If traveling with just the 10 m (33 ft) extension, the stinger section must be stowed on the boom base section, not on the extension base section.
Counterweight:
2.
Jobsite travel only on firm, level surface.
a.
3.
Main boom shall be fully retracted.
4.
Main boom angle: 3 degrees minimum, 30 degrees maximum.
5.
Maximum travel speed: 4 km/h (2.5 mph).
6.
With the boom over the front, the counterweight used can be from 0 kg to 8170 kg (18,000 lb) or 10,900 kg (24,000 pounds). Travel with the boom over the rear is not permitted with insert(s) erected.
7.
Swing lock and pin shall be engaged.
8.
Auxiliary hoist or IPO counterweight must be installed.
9.
Hookblock must be removed from main boom nose.
3.
Main boom shall be fully retracted.
4.
Main boom angle: 3 degrees minimum, 30 degrees maximum.
5.
Maximum travel speed: 4 km/h (2.5 mph).
6.
b.
With the boom over the front, the counterweight used can be from 0 kg to 8170 kg (18,000 lb) or 10,900 kg (24,000 pounds). With the boom over the rear, the counterweight used must be from 5440 kg (12,000 lb) to 8170 kg (18,000 lb).
7.
Swing lock and pin shall be engaged.
8.
Hookblock must be removed from main boom nose.
9.
Headache ball may be reeved over boom extension, hanging 0.9 m (3 feet) below sheave.
10. Suspension air bags shall be inflated. 11. The tires shall be properly inflated.
10 m (33 ft)/17 m (56 ft) Extension Plus One or Two 6 m (20 ft) Insert(s Travel is permissible under the following conditions.
GROVE
10. Headache ball may be reeved over boom extension, hanging 0.9 m (3 feet) below sheave. 11. Suspension air bags shall be inflated. 12. The tires shall be properly inflated.
Published 09-14-2012, Control # 132-07
3-33
3
