TMS800E OPERATOR’S MANUAL
LUBRICATION
14. Front Axle Brake Camshafts Lube Type - EP-MPG Lube Interval - 1000 hours Lube Amount - Until grease extrudes Application - 4 grease fittings ___ Correct: Lube level at bottom of filler hole. - - - Incorrect: Lube level below filler hole.
15. Rear Aluminum Wheel Pilots Lube Type - ASC Lube Interval - When wheels are removed for service. Lube Amount - Generously coat the wheel pilot or hub pads with anti-seize (ASC) compound. Do not apply anti-seize compound to the face of the wheel of the hub. Application - Brush on; 8 places
FIGURE 5-1 NOTE:
Figure 5-1 pertains to the differentials and the planetary hubs and wheel bearings.
17. Rear Rear Axle Differential
16. Front Rear Axle Differential
Lube Type - SSGL-5
Lube Type - SSGL-5 Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, fill, change filter, and clean magnetic drain plug every 80,00 km (50,000 mi) or 2 years, whichever interval occurs first.
Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, refill, and clean magnetic drain plug every 80,00 km (50,000 mi) or 2 years, whichever interval occurs first.
CAUTION
CAUTION Axle fluid levels shall be adjusted to bottom of fill plug threads. Check with crane on level ground, at its normal ride height, cold or room temperature oil only and after a 30 minute drain-down time.
Axle fluid levels shall be adjusted to bottom of fill plug threads. Check with crane on level ground, at its normal ride height, cold or room temperature oil only and after a 30 minute drain-down time.
CAUTION
CAUTION If the makeup amount is substantially more than 0.23 liter (0.5 pint) check for leaks. Lube Amount - Capacity - 23 liters (49 pints) Normal makeup - less than 0.23 liter (0.5 pint) Application - Fill to bottom of fill plug threads. NOTE:
6626
If the makeup amount is substantially more than 0.23 liter (0.5 pint) check for leaks. Lube Amount - Capacity - 17.5 liters (37 pints) Normal makeup - less than 0.23 liter (0.5 pint) Application - Fill to bottom of fill plug threads. 18. Rear Axle Brake Slack Adjusters
Lube level (Figure 5-1) close enough to the hole to be seen or touched is not sufficient. It must be level with the hole. When checking lube level, also check and clean housing breathers.
Lube Type - EP-MPG
5
Lube Interval - 1000 hours Lube Amount - Until grease extrudes Application - 4 grease fittings 19. Rear Axle Brake Camshafts Lube Type - EP-MPG Lube Interval - 1000 hours Lube Amount - Until grease extrudes Application - 4 grease fittings
GROVE
Published 09-14-2012, Control # 132-07
5-7
