TMS800E OPERATOR’S MANUAL •
SET-UP AND INSTALLATION
Use an auxiliary crane to couple the holding device to the connection eyes (3) on the auxiliary boom nose and lift it to the left onto the main boom head.
•
Align the auxiliary single-sheave boom nose so that the bearing point (2) lines up to the front bore holes in the holding device.
•
Secure the auxiliary single-sheave boom nose to the holding device using a pin (1).
•
Secure the pin (1) with a retaining pin (4).
•
Depending on the application, bring the auxiliary singlesheave boom nose into transport position or working position.
Removing the Auxiliary Single-Sheave Boom Nose
2
1
5 6 3
4
6435-2 FIGURE 4-70 •
Remove the retaining pins and draw all the pins out of the bores and bearing points.
•
In the transport position, the auxiliary single-sheave boom nose is positioned to the side of the main boom head and is fastened with two pins.
•
Lift the auxiliary single-sheave boom nose from the head of the main boom.
•
Insert the two thin pins (1) and (3) into the bearing points (2) and (4) on the auxiliary single-sheave boom nose Figure 4-70.
•
Insert the two pins (5) into the mounting brackets (6) in front on the auxiliary single-sheave boom nose.
•
Secure all pins using retainer pins.
1
RIGGING THE AUXILIARY SINGLE-SHEAVE BOOM NOSE 6435
Rigging in Transport Position
FIGURE 4-69 •
Attach an auxiliary crane to the connection eyes of the boom nose.
In the working position, the auxiliary single-sheave boom nose is positioned in front of the main boom head and is fastened with three pins (1) Figure 4-69. •
1 w2465a
Remove the retaining pins and draw all the pins out of the bores and bearing points.
In the transport position, the auxiliary single-sheave boom nose is positioned to the side of the main boom head and is fastened with two pins.
GROVE
FIGURE 4-71 On the left side of the main boom head there is a holding device. In transport position, the boom nose is connected to the rear bore holes on the holding device Figure 4-71.
Published 09-14-2012, Control # 132-07
4-33
4
