TMS800E OPERATOR’S MANUAL 5.
Extend boom approximately 60.9 cm (2 feet).
6.
Raise boom above horizontal.
NOTE:
7.
SET-UP AND INSTALLATION 11. Lower the boom.
Step 7 is stowing with the 7 m (23 ft) section and 10.1 m (33 ft) section together. If the 7 m (23 ft) section remained on the boom, proceed to step 9.
Use the tag line to maintain control of the boom extension, and swing the extension into the stowed position Figure 4-46.
DANGER If the 33 ft lattice extension (1, Figure 4-47) does not engage the ramp (2, Figure Figure 4-47) correctly or does not align with the front stowage bracket (2, Figure 4-48) correctly, STOP. DO NOT continue to stow the boom extensions until they are properly secured at these two points. DO NOT climb onto decking or walk under boom extensions. Sever injury or death may occur if the front stowage bracket and ramp are not properly attached to the boom extensions; the boom extensions may fall or swing away from the main boom stowage brackets.
FIGURE 4-46
6645-5
NOTE:
8.
9.
Step 8 is with the 7 m (23 ft) section stowed on boom. If stowing the 7 m (23 ft) section and 10.1 m (33 ft) section together, proceed to step 10.
Use the tag line to maintain control of the boom extension Figure 4-46, and swing the extension into stowed position until tag line can be attached to superstructure.
Contact Manitowoc CraneCARE for correct adjustments if unable to align the lattice extension with the stowage brackets. 12. Remove the stowage pin from the holder at the front mount. Secure the lattice extension (1, Figure 4-48) to boom front stowage bracket (2) using stowage pin (3) and clip pin (4). 2
3
Raise the boom to ensure wear pad rests against bumper plate on ramp Figure 4-47.
10. Completely retract boom so that the boom extension (1, Figure 4-47) stows on the ramp (2) and front stowage brackets.
4
4
1
FIGURE 4-48
6642-46
DANGER Never remove the stowage pins from the right side boom nose lugs (1, Figure 4-49) until the 10.1 (33 ft) lattice extension has been properly secured to the stowage ramp (2, Figure 4-47) and front stowage bracket (2, Figure 4-48).
1 6642-47
GROVE
Sever injury or death may occur, boom extensions will fall from the main boom if not secured properly.
2
FIGURE 4-47
13. Remove pins from right side boom nose lugs (1, Figure 4-49). Stow the pins in pin holders (2) on boom extension and install retainer clips.
Published 09-14-2012, Control # 132-07
4-21
