CHAPTER 15 OPTIONAL FEATURES & ACCESSORIES NOTE: Installation information for all of the Option al Features & Accessories, described in this chapter is provided in the Set-up & Assembly chapter, except for the Safety Chain, which is described in the Transporting chapter. ENDGATE 2ND CYLINDER KIT
SHEAR BOLTS Additional Shear Bolts for both the Main Drive Shear Device and the Apron Transmission Driven Sprocket Shear Devices are available in packaged quantities of (8) Bolts and Locknuts per package.
The Endgate 2nd Cylinder Kit (804492) is available for mounting on Spreaders that are used over very rough terrain. The Kit includes a Hydraulic Cylinder. attach ing hardware and interconnecting Hoses and Piping.
Order Part Number 080079 for a package of (8) 1/4 x 1-1/2 Grade 8 Shear Bolts and Locknuts for the Main Drive Sprocket or Part Number 900091 for a package of (8) 1/4 x 1 Shear Bolts and Locknuts for Apron Transmission Driven Sprocket Shear Device.
HYDRAULIC ENDGATE
SPLASH SHIELD & SIDE RAILS
Hydraulic Endgate package (804489) is available for liquid manure handling or other applications.
When required or desired. the Spreader can be equipped with a Splash Shield and Side Rails package (804494). The Splash Shield can be conveniently at tached to the top front edge of the Spreader using the hardware provided. The Side Rails are likewise con veniently attached to the top edges of each side of the Spreader Box using hardware provided.
LITTER PAN If the Spreader is going to be transported on a public
highway. a Litter Pan (804867) should be obtained and installed to prevent manure from falling-out the back of the Spreader and onto the highway. The Litter Pan package is designed to be used in conjunction with an accessory Hydraulic Endgate or without an Endgate provided a Manual Trip Lever package is separately ordered and installed.
LITTER PAN MANUAL TRIP LEVER PACKAGE If the Spreader is equipped with a Litter Pan but NOT
equipped with a Hydraulic Endgate package a Litter Pan Manual Trip Lever package (804864) MUST be ordered and installed separately.
SAFETY CHAIN NOTE: If the Spreader is going to be transported
WHEELS & WHEELS WITH TIRES The following is a listing of the various Wheels and Wheels with Tires combinations for the various model Spreaders: 803027 Set of Two 8 x 20" Drop Center Truck 8-bolt Rims 803111 Set of Two 10.5 Used Tires Mounted on 8 x 20" Drop Center Truck Rims 803028 Set of Two 10.00 x 20 12-ply Ribbed tread. Recapped Tires Mounted on 8 x 20" Drop Center Truck Rims
on a public highway, a Safety Chain package (803098) should be obtained and installed per details in the Transporting chapter.
47
