3 Planning of bodies 3.3 Dimensions, weights, vehicle overall length, height, and width 3.3 Dimensions, weights, vehicle overall length, height, and width
a Risk of accident The vehicle tire load capacity may not be exceeded by overloading the vehicle beyond its specified gross vehicle weight. The tires could overheat and suffer damage. This could cause an operator to lose control of the vehicle and cause an accident with possible injury or death.
i Information about changes in weight is available from the department responsible e page 15.
Information on the permissible axle loads can be found in this manual and on the vehicle model plate. All legal provisions governing the permissible vehicle length, height, and width must be taken into account when planning bodies.
Dimensions and weight details can be found in the drawings and technical data. They are based on a vehicle that is fitted with standard equipment. Weight tolerances of r3% in production must be taken into consideration. The permissible axle loads and the maximum permissible gross vehicle weight specified in the technical data may not be exceeded. The technical data can be found in the vehicle documents, on the vehicle model plate.
i
