37R116 Axle Service Manual
TRUNNION MOUNT AXLE WITH BRAKE PARTS DESCRIPTION ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
DESCRIPTION Axle Shaft Face Seal Bearing Cone Bearing Cup Trumpet Arm Housing Socket Head Screw Washer O-Ring Bearing Cup Bearing Cone Internal Ring Gear Dowel Pin Bronze Spacer Planet Carrier Assembly Shim 0.10, 0.18, 0.25, 0.50 Clamp Plate Socket Head Screw Pressure Relief Valve Trunnion Cap Cap Screw Washer Shim .004", .007", .010", .020" Thrust Washer Plug Front Trunnion Bushing
QTY 2 2 2 2 2 48 62 2 2 2 2 24 2 2 AR 2 8 2 1 12 12 AR 1 2 1 2
ITEM 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
8
DESCRIPTION Seal Socket Head Screw Trunnion Journal I.D. Plate - Not Serviceable Screw Dowel Pin Differential Carrier Assembly Trunnion Sleeve Thrust Washer Seal Rear Trunnion Piston Inner Backup Ring Piston Inner Seal Piston Outer Seal Piston Outer Backup Ring Piston Reaction Plate Friction Plate Sun Gear Retaining Ring Brake Abutment Spring Plug Seat Insert Bleeder Screw Magnetic Plug and O-Ring
QTY 2 14 1 NA 4 2 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 8 2 2 2 2
