37R116 Axle Service Manual
Figure 240 Using a feeler gauge check between cone and shaft shoulder in several places to be sure bearing cup is properly seated.
Figure 237 Heat outer wheel bearing cone. Reference bearing heating and freezing guidelines on page 23.
Face Seal Installation
Figure 238 Install outer wheel bearing cone.
Figure 241 Clean seal bore in axle shaft with solvent. Reference face seal installation instructions on page 19.
Figure 239 Tap inner race of bearing to assure it is properly seated on shaft. NOTE: The old bearing race, as shown, works well for this procedure and minimizes the risk of damaging the bearing.
Figure 242 Clean metal ring sealing surface with a lint free cloth.
72
