37R116 Axle Service Manual
Trumpet Arm Reassembly
Figure 231 Freeze inner wheel bearing cup and install. Reference bearing heating and freezing guidelines on page 23.
Figure 234 Freeze outer wheel bearing cup and install.
Figure 232 Using a soft bar tap around bearing cup to assure it is properly seated in bore.
Figure 235 Using a soft bar tap around bearing cup to assure it is properly seated in bore.
Figure 233 Using a feeler gauge check between cup and housing in several places to be sure bearing cup is properly seated. Reference bearing heating and freezing guidelines on page 23.
Figure 236 Using a feeler gauge check between cup and housing in several places to be sure bearing cup is properly seated.
71
