37R116 Axle Service Manual
PAD MOUNT AXLE WITHOUT BRAKE PARTS DESCRIPTION ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14
DESCRIPTION Axle Shaft Face Seal Bearing Cone Bearing Cup Trumpet Arm Housing Socket Head Screw Washer Magnetic Plug and O-Ring O-Ring Bearing Cup Bearing Cone Internal Ring Gear Dowel Pin Retaining Ring
QTY 2 2 2 2 2 48 48 2 2 2 2 2 24 2
ITEM 15 16 17 18 19 20 21 22 23 24
6
DESCRIPTION Bronze Spacer Planet Carrier Assembly Shim 0.10, 0.18, 0.25, 0.50 Clamp Plate Socket Head Screw Sun Gear Dowel Pin Differential Carrier Assembly Screw I.D. Plate - Not Serviceable
QTY 2 2 AR 2 8 2 2 1 4 NA
