37R116 Axle Service Manual
Figure 198 Inspect tooth contact pattern on ring gear. Compare to tooth bearing charts on pages 25 & 26 and make adjustments if necessary as indicated.
Figure 196 Install stub shaft. NOTE: The sun shaft and a socket can be used to perform this procedure.
Hydraloc Seal Retainer Assembly and Installation
Figure 199 Apply continuous coat of Loctite 620 or equivalent to outside diameter of inner Hydraloc seal.
Figure 197 Step #1 Hold pinion and rotate side gear five turns in each direction. Differential clutch must turn freely with a maximum torque of 34 Nm [25 LBF/FT]. Step #2 Hold side gear and rotate pinion in both directions to make several passes through the gear contact checking compound on the ring gear.
Figure 200 Using appropriate driver install inner Hydraloc seal. NOTE: Seal is installed with sealing lip down or towards center of seal retainer. Reference tool drawing on page 90.
