37R116 Axle Service Manual
Figure 174 Install differential bearing adjusting nut.
Figure 177 Lock or hold pinion shaft from turning.
Differential Assembly Installation
Figure 178 Remove (1) of (2) ring gear cap screws and mark head of remaining screw for identification purposes.
Figure 175 Paint 5 to 6 ring gear teeth with contact checking compound.
Figure 179 Apply Loctite 262 or equivalent to (15) ring gear mounting cap screws and install with washers. Run down but do not tighten. IMPORTANT: Perform the procedures shown in figures 179-181 in a timely manner before the Loctite begins to cure.
Figure 176 Install differential assembly in housing.
60
