37R116 Axle Service Manual
Figure 42 Grind the cutting edge of a chisel to a radius as shown.
Figure 39 Remove flange.
Figure 40 Remove v-ring seal from flange.
Figure 43 Use rounded tip chisel to expand and remove wear sleeve by striking evenly across the width of the sleeve in the three marked locations. IMPORTANT: Do not cut through wear sleeve as damage to the flange will occur.
Pinion Seal Retainer Cartridge and Seal Removal
Figure 41 Mark flange wear sleeve in three equally spaced locations as shown across the full width of sleeve.
Figure 44 Install (2) M8 screws and flat washers in puller holes.
37
