37R116 Axle Service Manual
PAD MOUNT HYDRALOC DIFFERENTIAL PARTS DESCRIPTION ITEM 1 2 3 4 5 6 7 8 9 9A 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
DESCRIPTION Socket Head Screw Cap Screw Seal Retainer with (2) Plugs Plug Seal Ring Nut - Differential Bearing Adj. Cap Screw Retainer - Differential Plug - Tank Port Plug - Pressure Port O Ring Cap Screw Washer Seal - Outer Ring - Piston Sleeve Wear Seal Inner Cup Cone Bearing Metric Plug - 3mm Flange Half Seal - Ring Inner Ring - Inner Backup Piston Seal - Ring Outer Ring - Outer Backup Plate - Reaction Plate - Friction Washers - Side Gear Splined Hub Gear Thrust Washer Pinon - Side Differential Spider - Differential
QTY 1 4 1 1 2 1 4 1 1 1 1 16 16 1 2 1 1 2 2 1 1 1 1 1 1 1 7 6 2 1 4 4 4
ITEM 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
10
DESCRIPTION Side Gear Differential Case Assembly Case - Differential Half Washer Capscrew Ring Gear Housing Carrier Seat Insert Screw - Brake Bleeder Plug Nut - Differential Bearing Adj. Lock - Differential Adj. Nut Plug - Magnetic Pinion Pinion Bearing Cone - Inner Pinion Bearing Cup - Inner Shim .004",.007",010" Pinion Bearing Cone - Outer Pinion Bearing Cup - Outer O Ring Seal - Pinion Grease Fitting Cartridge Seal Retainer Seal - Grease Thrust Washer Seal - V Ring Sleeve Wear Flange O Ring Spacer O Ring Spacer Pinion Nut - Pinion Shaft
QTY 1 1 1 12 12 1 1 2 2 2 1 1 2 1 1 1 AR 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
