Operation Opening/closing the rear window Danger!
A
In order to avoid crushing and injury, close the rear window when driving the machine!
☞ Lock the rear window with the lock lever ☞ Remove the lock lever from the guide only in case of an emergency ☞ Opening the rear window • Unlock lock lever A in the direction of the arrow • Open the rear window • Engage lock A in the end of lever B with an audible click (arrow) ☞ Closing the open rear window • Lock the rear window in the reverse order
B
Fig. 47: Rear window lock
Interior light operation (cab) The interior light is switched on via a contact switch when opening the door. ☞ Switch the light on/off permanently • See the switch on the interior light
Fig. 48: Switch for interior light
00 0290 775 2 - BA SCORPION
3-15
