Operation
Operation 3.6 Cab Safety instructions regarding cab entrance and exit • Remove dirt (oil, grease, earth, snow and ice) from handles, footholds and shoes before entering the cab • Use only the machine footholds, platforms and handles for entering the cab • Face the machine as you enter and leave it
Safety instruction – side window (right) The right-hand side window (cab) is a safety element and must be immediately replaced by a new one even if it is only slightly damaged.
Danger! In order to avoid danger of crushing or accidents, do not put the machine into operation – or stop the machine immediately – if the side window on the right is brocken!
☞ Keep a safe distance to the telescopic boom as you lower it to the ground
Fig. 44: Danger in case of broken side window
carefully ➥ – see Operating the telescopic boom on page 3-61 ☞ Stop the diesel engine and remove the ignition key ☞ Apply the parking brake ☞ Have the side window replaced by an authorised workshop
Locking and unlocking the door Danger! A
In order to avoid danger of accidents, safely lock the upper and lower doors when using the machine!
☞ Lock the upper cab door with the lower door, or secure it in the door arrester of the cab ☞ Lock the lower cab door
☞ Outside: pull handle A outwards ☞ Inside: press door opener B upwards To open the upper cab door (side window) – see Opening the upper cab door to a gap on page 3-14
B
Notice! Apply grease to the door lock at regular intervals.
Fig. 45:
Opening and locking the door
00 0290 775 2 - BA SCORPION
3-13
