Operation Load stabiliser/hose burst valve indicator light (yellow) Indicates that the load stabiliser is switched on, and that the hose burst valve is switched off. ➥ – see chapter 3 “Switching the load stabiliser ON or OFF” on page 3-48
65
66
67
57
Indicator light (green) – driving direction Indicates forwards/reverse driving direction
Temperature gauge with acoustic warning – engine (coolant) Indicates the engine temperature detected by a sensor. ➥ Engine temperature should be between 80 and 105 °C. Max. admissible temperature is 110 °C. The acoustic warning sounds from 115 °C
90
Indicator light (green) – front axle wheel position Indicates that the front axle wheels are parallel to the centre line of the machine.
94
Indicator light (green) – rear axle wheel position Indicates that the rear axle wheels are parallel to the centre line of the machine.
00 0290 775 2 - BA SCORPION
3-9
