Operation Indicator lights and indicators on the instrument panel 62
63
61
61
Indicator light (red) – hydraulic oil temperature Indicates that the temperature in the hydraulic system is too high.
Indicator light (red) – drive boost pressure monitoring If this indicator light comes on with a running engine and a released parking brake, and/or during machine operation, this is a sign of a boost pressure drop in the drive! • Stop the machine immediately to avoid further damage to the drive • Stop the engine and apply the parking brake • Have the error repaired by an authorised workshop
Indicator light (red/yellow/green) – diesel particle filter (option) The LED indicates the status in the exhaust gas particulate filter system.
Indicator light (red) – fuel system water separator (option) Indicates that the water separator of the fuel prefilter contains water: ➥ – see chapter 5 “Checking/cleaning the additional fuel filter (water separator, option)” on page 5-4 Indicator light (red) – Caution! (option)
60
59
58
3-8
Indicator light (yellow) – accelerator pedal lock (option) Indicates that the accelerator pedal lock (manual throttle) is switched on.
Indicator light (red) – overload cutoff (option) Indicates that the hydraulic functions “Raising, Lowering, Dumping In/Out and Extending” locked by the safe load indicator are available again.
00 0290 775 2 - BA SCORPION
