Operation 51
P
52
Parking brake indicator light (red) Comes on when the parking brake is applied. An electric driving interlock prevents starting the diesel engine when the parking brake is not applied! Engine oil pressure indicator light (red) The indicator light comes on when the ignition is turned on and goes out as soon as the engine runs. Comes on if the engine oil pressure is too low. In this case: ☞ Stop the machine ☞ Stop the engine immediately and check the oil level
53
Indicator light (red) – continuous operation of 3rd control circuit (hydraulics) Comes on during operation of an attachment with its own hydraulic circuit (e.g. rotary broom with hydraulic motor).
46
Right/left turn indicator light (green) for rear attachment (option) Flashes intermittently when the turn indicators are used and a front or rear attachment is connected electrically.
45
Right/left turn indicator light (green) Flashes intermittently when the turn indicators are used
00 0290 775 2 - BA SCORPION
3-7
