If the key is held for 3s or the Enter key is pressed following the Ulock key, the Umbrella Lock will be cancelled.
Hold for 3s or follow with the Enter key to de-activate Umbrella Lock
The size of the Umbrella Lock zone is set by parameter "Umbrella Lock Distance". When the zone is activated or moved, the set number of shields on each side becomes part of the active Umbrella Lock zone. The display will indicate if the Umbrella Lock zone runs into another Umbrella Lock zone or the end of the face. The display also shows how many more shields are included in the Umbrella Lock zone.
Active Umbrella Lock Displays These display lines are shown as the default display; line2 of the display will continue to show the normal sensor and shearer position information. Display Help Text #129 ULOCK !!!
Umbrella Lock is active; this is the center shield.
#129 ULOCK >X more
Umbrella Lock is active here and X shields to the right.
#129 ULOCK Overlap
This shield is in two umbrella lock zones; zones cannot be cleared or moved from this shield.
Umbrella Lock Messages These displays are shown when the Umbrella Lock zone is initiated or moved. They only display for Key-time and then they go away. Display Help Text Umbrella activated. Not for maintenance!! Umbrella activated. For travel only!!
Umbrella Lock is not intended for maintenance; use the black Local Lockout. Umbrella is intended only for traveling across face; not for maintenance.
When shields are first included in the Umbrella Lock zone, a short audible warning will sound. When moving the Umbrella Lock zone causes some shields to be released (i.e., no longer within the zone), those shields will provide an audible warning that the Umbrella Lock no longer covers those shields. This warning is longer than the new-Umbrella Lock warning and the Umbrella Lock restrictions are not actually released until the warning sound is completed.
