________________________________________ Replacement of wear parts Power unit The power unit (Fig. 60) has been assembled as a unit and can be removed as a unit or as individual components. As soon as any component of the power unit is worn or damaged, the component must be replaced. The power unit consists of the following main components: ■
gear pump
■
hydrostatic pump
■
pump coupling
■
motor (200 hp)
■ reducer/motor coupling ■
reducer
■
torque limiter
■
connecting tube
Fig. 60: Power unit main components Taperlock bushing Reducer Torque limiter Motor (200 HP)
Coupling
Coupling Hydrostatic pump
Companion flange Connecting tube Connecting tube Gear pump
